The LDS-25 36ST double spindle CNC lathe delivers synchronized dual-spindle turning for high-efficiency batch production. Engineered by a seasoned cnc lathe manufacturer, it excels as a precise, space-saving metal cutting cnc machine.
| LDS-25 36ST Double Spindle CNC Lathe Parameters |
| Serial number |
Item |
Unit |
25-ST |
36-ST |
| 1 |
Barrel spindle unit through hole |
mm |
Φ36 |
Φ46 |
| 2 |
Maximum swing diameter over bed |
mm |
Φ150 |
| 3 |
Spindle |
Spindle nose type |
|
A2-4 |
| 4 |
Maximum spindle speed |
r/min |
5000 |
| 5 |
Spindle set speed |
r/min |
1-3000 |
| 6 |
Maximum bar through-hole diameter |
mm |
Φ25 |
Φ35 |
| 7 |
Tool mounting type |
mm |
Linear tool arrangement |
| 8 |
Height from linear tool to spindle center |
mm |
45 |
| 9 |
Lead screw and guideway protection method |
|
Semi-protected |
| 10 |
Power head |
|
Depending on the process conditions |
| 11 |
Height from spindle center to floor |
mm |
High: 1420; Low: 1160. |
| 12 |
Lathe bed inclination |
Degree |
35° |
| 13 |
X1-axis effective travel |
mm |
1100 |
| 14 |
X2-axis effective travel |
mm |
| 15 |
Z1-axis effective travel |
mm |
300 |
| 16 |
Z2-axis effective travel |
mm |
| 17 |
X/Z axis rapid traverse setting speed |
mm |
30 |
| 18 |
X-axis lead screw diameter & pitch |
mm |
3210 |
| 19 |
Z-axis lead screw diameter & pitch |
mm |
3210 |
| 20 |
X-axis linear guideways |
mm |
30 Roller |
| 21 |
Z-axis linear guideways |
mm |
35 Roller |
| 22 |
Overall dimensions (L×W×H ) |
mm |
2600*1950*2000 |
| 23 |
Net weight |
KG |
4300 |
| 24 |
Roundness of machined workpiece |
mm |
0.005 |
| 25 |
Machining accuracy |
mm |
0.008/200 |
| 26 |
Cylindricity of machined workpiece |
mm |
0.005 |
| 27 |
X/Z-axis repeat positioning accuracy |
mm |
0.005 |
| 28 |
Accuracy class of guideways |
mm |
H |
| 29 |
Accuracy class of lead screw |
mm |
C3 |
| 30 |
Collet taper runout |
mm |
≤0.015 |
| 31 |
Spindle radial runout |
mm |
0.0025 |
Optimized Multi-Functional Lathe Solution for Rotary Components
Designed for precision machining of rotary elements such as discs and short shafts, the LDS-25 36ST is a double spindle CNC lathe developed by an experienced cnc lathe manufacturer. Its twin-spindle configuration allows simultaneous operations on both ends of a workpiece, consolidating multiple machining steps into a single setup. This functional positioning addresses the needs of manufacturing engineers and production planners aiming to reduce cycle times and setup errors within automated environments. The machine supports integration with automated feeding systems, enabling continuous, unattended operation suitable for high-efficiency, low-cost mass production workflows involving cnc cutting machine tools.
Precision Engineering and High-Performance Specifications
This double spindle metal cutting cnc machine features a turret-type design with technical capabilities tailored to high-accuracy machining demands. It incorporates synchronized twin spindles, capable of speeds up to 5000 r/min, and maintains machining tolerances within 0.005 mm roundness and 0.008 mm accuracy per 200 mm. The lathe’s compact footprint replaces dual single-spindle systems, embodying a sophisticated design including linear tool arrangements, semi-protected lead screws and guideways, and high-class guideway and lead screw accuracy. With dimensions of 2600×1950×2000 mm and robust construction weighing 4300 kg, the machine delivers consistent, repeatable performance that meets stringent industrial machining standards.
Integration Potential in Diverse Industrial Applications
The LDS-25 36ST serves critical roles in industries requiring reliable CNC machining, such as automotive, electronics, hydraulic, and hardware manufacturing. It facilitates batch production of transmission blanks, pump shafts, and other rotary components with minimal manual intervention. Its ability to replace two single-spindle lathes reduces floor space and capital expenditure. Incorporated into assembly lines with robotic workflows, this cnc cutting machine enhances throughput while maintaining dimensional integrity. The solution addresses demands for fast changeovers and repetitive precision, making it an asset for manufacturers focused on productivity, quality, and scalable operations using advanced cnc machine tools.
Product Advantages
Structural and Design Efficiency for Integrated Machining
The LDS-25 36ST’s twin-spindle layout exemplifies thoughtful structural design by consolidating dual machining centers into a single machine, delivered by a reputable cnc lathe manufacturer. This integration eliminates multiple clamping and datum referencing errors traditionally associated with separate machines. The turret-type tool post facilitates quick tool changes and reliable cutting performance. Key design elements include semi-protected lead screws, high-precision roller linear guides, and a lathe bed inclined at 35°, which enhance positional accuracy and tool life. This compact, dual-spindle structure enables space-saving factory layouts without sacrificing machining capability, thereby optimizing both footprint and system modularity typical of a leading cnc cutting machine platform.
Enhanced Performance, Operational Usability, and ROI
From a performance perspective, the LDS-25 36ST offers synchronized spindle operation that significantly reduces cycle times and labor requirements on production lines utilizing cnc machine tools. Its automation compatibility supports continuous, unattended operation, minimizing downtime and allowing personnel to focus on productivity monitoring. The user interface allows precise control over axis travels and feeds, with repeatability within 0.005 mm ensuring tight tolerances on finished parts. The lathe’s robust build contributes to long-term machine stability, reducing maintenance needs and enhancing return on investment for manufacturers seeking reliable, high-throughput metal cutting cnc machine solutions.
Use Scenarios
Batch Production in Automotive and Hydraulic Components ManufacturingIn automotive and hydraulic manufacturing environments, the LDS-25 36ST functions as a core production asset to machine transmission blanks, pump shafts, and precision fittings. Its twin-spindle configuration facilitates end-to-end machining of compact rotary parts in a single setup, enhancing production throughput and reducing manual handling. The machine’s compatibility with automated feeders aligns with high-volume mass production lines that require sustained operational uptime and precise adherence to dimensional specifications. This cnc cutting machine supports workflow integration with robotic handling systems, ensuring consistent part quality and efficiency compliance in demanding industrial contexts such as automotive drivetrain assembly and fluid power component fabrication.
Role in Electronics and Precision Hardware ManufacturingThe LDS-25 36ST is highly applicable within electronics and general hardware production, where small, precision shafts and components such as heat sink mandrels, bolts, and studs require repeatable accuracy. Operating within production cells, this cnc lathe manufacturer-designed system supports rapid changeovers and minimal manual intervention, essential for flexible manufacturing setups. Its dual-spindle operation and turret tooling design enable simultaneous machining of multiple workpiece features, optimizing cycle times while sustaining micron-level tolerances. The machine’s compact footprint and automation readiness allow seamless integration into electronic parts manufacturing lines, delivering reliable performance that underpins quality control and production scalability ambitions using advanced cnc cutting machine tools.
FAQ
What types of materials can the LDS-25 36ST Double Spindle CNC Lathe machine handle?
The LDS-25 36ST is designed for high-precision machining of various metals commonly used in industrial sectors, including automotive and electronics. Its robust construction supports machining of metal components on a metal cutting CNC machine, ensuring consistent accuracy and repeatability.
Can Jinlaoda customize the CNC lathe according to specific production needs?
Yes, Guangdong Jinlaoda CNC offers tailored solutions based on client requirements, including adjustments in automation, tooling, and spindle configurations. As a professional CNC lathe manufacturer, we support customization to align with your production scale and material specifications.
What installation and training support is provided with the CNC machine tools?
Jinlaoda provides comprehensive installation assistance and operator training. Our technical team ensures proper setup and smooth integration into your production line. Ongoing support maximizes machine uptime and maintains the precision standards expected from our CNC cutting machines.
How does the twin-spindle design improve production efficiency in a batch manufacturing environment?
The LDS-25 36ST’s synchronized twin spindles allow simultaneous turning on both ends of a workpiece within one setup, drastically reducing cycle times. This design replaces two single-spindle units, saving floor space and lowering labor costs, making it ideal for high-volume production with automated feeding systems.
